Over 25 years experience in machine build, repair and calibration.

MACHINE LEVELING

GEOMETRY correction

Over time and through usage most machines will require levelling and geometry correction. ALiGN has the skill needed and the equipment required to get machines back within tolerance.

Providing large amounts of quantitative information, this test is done before and after any changes are made to a machine and both sets of results are included in the calibration report.

Ballbar Analysis

Verifies the postional accuracy of each axis., and the results are included in the Calibration Report. Changes are then made within the CNC control to correct this accuracy within microns throughout the travel.

Interferometry

Linear Analysis

Machine idling before cutting shapes from metal

machine reporting

Detailed reports that include all Ballbar and Linear test results, along with notes explaining level accuracy with geometry findings and corrections. Prove to customers that your equipment meets their requirements.

Results can also be used for ISO compliance.

Side view of CNC machine being levelled.

expert level service

Extensive knowledge of all types of machine styles including vertical and horizontal

machining centers, boring mills, gantry mills, gundrills and EDMs.

Experience with many of the following controllers and more.
